Product Details:
Payment & Shipping Terms:
|
| LED Chip: | Epistar | Cabinet Material: | Die-casting Aluminum |
|---|---|---|---|
| Working Voltage: | 110V - 220V ±15%, 50Hz | Warranty: | 2 Full Years |
640mm x 640mm HD Indoor 5mm SMD2020 Die-casting Aluminum Cabinet Stage Rental LED Display
Quick Info.
Brand: CNSRYLED
Pixel Pitch: 4.81mm
LED Encapsulation: SMD2020
Color Configuration: 1R1G1B 3in1
Module Size: 250mm x 250mm
Cabinet Size: 500mm x 500mm
Cabinet Material: Die-casting Al
Warranty: 2 Full Years
Certifications: CE, LVD, RoHS
Place of Origin: Shenzhen, China
Specs.
| Parameter | P5 | |
| Module |
Pixel Configuration | 1R1G1B SMD2020 |
| Pixel Pitch | 5mm | |
| Module Resolution(W×H) | 64dots x 32dots | |
| Module Size | 320mm x 160mm | |
| Module Weight | 0.35kg | |
| Max Power Consumption | 30W | |
| Cabinet(Panel) | Module Qty | 8pcs |
| Cabinet Resolution(W×H) | 128dots × 128dots | |
| Cabinet Size | 640mm x 640mm | |
| Weight of One Cabinet | 10kg | |
| Cabinet Flatness | ≤0.2mm | |
| Cabinet Material | Die-casting Cabinet | |
| Optical Parameters | Brightness Calibration by Per Dot | Yes |
| White Balance Brightness | ≥1,500nits | |
| Color Temperature | 3200K--9300K(adjustable) | |
| View Angle | Horizontal 160°, Vertical 160° | |
| Brightness Uniformity | ≥97% | |
| Max.Contrast | 4,000:1 | |
|
Electrical Parameters |
Max Power Consumption(㎡) | 800W/㎡ |
| Average Power Consumption(㎡) | 266W/㎡ | |
| Input Voltage | AC 110V - 230V ± 15% | |
| Processing Performance | Driving Mode | 1/16scan |
| Frame Rate(Hz) | 120frame/sec | |
| Refresh Frequency(Hz) | ≥3,840HZ | |
| Using Parameters | Best Viewing Distance(m) | 5m - 50m |
| Lifetime | ≥100,000hrs | |
| Working Temperature | -20°C - + 60°C | |
| Stored Temperature | -30°C - + 70°C | |
| Working Humidity(RH) | 10% - 90%(no dew formation) | |
| Stored Humidity(RH) | 10% - 95%(no dew formation) | |
| Waterproof | NO | |
| Statement: Product parameters table for reference only, the specific subject to the actual. | ||
Competitive Advantages
1. HD play, delicate and clear.
2. Excllent encapsulte effect. Strong adaption to environment.
3. Higher cost performance, lower maintenance cost.
4. Small chip body combined with black mask, generating higher contrast ratio.
5. Strictly screening same LED wavelength, brightness voltage and etc to ensure the consistency of the whole screen.
6. High quality driving IC, combined with the control system which has more than 14bit processing, effecting a higher refresh rate.
7. High quality driving IC,combined with the control system which has more than 14bit processing, effecting a higher gray level.
8. Easy and fast to install and disassemble, without any tools.
|
Business Organizations
|
Supermarket, large-scale shopping malls, exclusive agency, chain shops, largescale sales, starrated hotels, restaurants, travel agencies, pharmacy. |
|
Financial Organizations |
Banks, negotiable securities, funds, insurance companies, pawnshops; Non-profit Organizations: Telecommunications, post offices, hospital, schools; |
|
Public Places |
Subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas,offices, commercial buildings, model rooms, property brokers; |
|
Entertainments |
Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course |
