Product Details:
Payment & Shipping Terms:
|
| Name: | Station Advertising Led Screen | Pixel Pitch: | 10mm |
|---|---|---|---|
| Module Size: | 160mm X 160mm | Led Chip: | DIP346 |
| Led Type: | 1R1G1B | Drive Method: | 1/4 Scan |
| Brightness: | 7500cd/sqm | Leds Brand: | Epistar |
| High Light: | LED advertising billboards,led advertisement board |
||
1R1G1B Aluminum LED Advertising Screens For Toll Station , DIP P10 LED display
Description
1, P10 1R1G1B led display, with 10000dots/sqm, which guarantee vivid and clear image effection.
2, Cabinets with Protection grade IP65 front and IP54 rear, suitable for all outdoor working environment.
3, Fast locks at the four sides of the cabinet, easy assemble and be piled up and be hoisted.
4, Backside maintenance. Exterior exposed module screws, easy dismantling.
5, Waterproof connectors, safe and steady.
Features:
(1) High brightness DIP LED is used for outdoor led display, keeps the display content visible even if facing the strong sunshine directly.
(2) With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.
(3) Weatherproof design, completely outdoor use.
(4) Easy for assembling and connection with the connector added.
(5) High color uniformity and clear image can bring you a vivid audio visual effect.
(6) Both front and rear access are available.
(7) The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.
(8) Use the same level of red, green and blue led chips, which makes the image display of whole led display more excellent and uniform.
Competitive advantages
1, Good quality
2, Good price
3, Good 24hours service
4, Prompt delivery
5, Energy-saving
6, Small order accepted
Specification:
|
Pixel Pitch |
10mm |
|
Pixel Density |
10000dots/sqm |
|
Color Configuration |
1R1G1B |
|
LED Package |
DIP346 |
|
Module Size |
160mm x 160mm |
|
Module Resolution |
16dots x 16dots |
|
Drive Mode |
1/4 Scan, Constant Current |
|
Brightness |
7500cd/sqm |
|
Viewing Distance |
10m-100m |
|
Viewing Angle |
H: 120°; V:120° |
|
Refresh Rate |
2000HZ |
|
Frame Rate |
120frame/sec |
|
Grey Scale |
16.7M colors(Synchronized) |
|
Color Temperature |
R.G.B brightness 256 level adjustable |
|
Power Input |
AC110V/ 220V ±10％, 50HZ |
|
Max Power Consumption |
800W/sqm |
|
Ave. Power Consumption |
300W/sqm |
|
Storage Temperature |
-40℃~+85℃ |
|
Working Temperature |
-20℃~+65℃ |
|
Blind Spot Rate |
<1/10000 |
|
MTBF |
>10,000 Hours |
|
Life Span |
>100,000 Hours |
|
Waterproof |
IP65 |
|
Operating Humidity |
10%~95% |
|
Control Method |
Synchronous, 3G, WIFI, USB |
|
Control PC |
With DVI Graphic card |
|
Operating System |
Win 98, Win2000, XP, Win7, Win8 etc |
|
Video Signal Mode |
RF, S-Video, RGB, RGBHV, YUV, YC etc |
|
Certificate |
CE, RoHS |
Applications:
|
Business Organizations |
Supermarket, shopping malls, star-rated hotels, travel agencies |
|
Financial Organizations |
Banks, insurance companies, hospital, schools |
|
Public Places |
Subway, airports, stations, parks, exhibition halls, stadiums, museums, commercial buildings |
|
Entertainments |
Movie theaters, stages |
Our Service and Mission
Pre-sale service
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide professional solutions based on customer's requirement.
4. Offer sample and all document as customers required.
5. Other services, such as factory visiting and so on.
In-sale service
1. Tracking report of production.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
After-sale service
1. Lifetime maintenance and software upgrade.
2. Complaint respond period not exceed 24 hours, maintenance guidance and problem solution supplied in 48 hours.
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
5. Engineer guide installation onsite if needed.
Product Images
