Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 6mm | Module Size: | 192mm X 192mm |
|---|---|---|---|
| Brightness: | 6500cd/sqm | Waterproof: | IP65 |
| Led Chip: | SMD3535 | Led Brand: | Nationstar |
| Led Display Size: | 8m X 6m Or Customized | Cabinet Size: | 960mm X 960mm |
| High Light: | Perimeter Led Screen,stadium advertising boards |
||
HD Digital Stadium Perimeter LED Display , 6mm SMD Perimeter LED Screen
Quick Detail:
1. Name:P6 stadium led display
2. Pixel Pitch:6 mm
3. Brightness:6500cd/m2
4. Recommended Viewing Distance:6-60m
5. Contrast:4000:1
6. Refresh Rate:1000HZ
Description
1. P6 , P7.62 , P8 , P10 , P12 , P16 are Available
2. Easy to install and maintenance
3. Widely used in indoor and outdoor advertising and media promotion, such as Exhibition,
Shopping mall, Football Stadium, Party etc
4. High quality with Vivid visual effect
5. Colorful moving videos and images
6. Environmental-protected and saving cost
7. Good sales service
8. Prompt delivery
Competitive Advantages:
1, Multi Use: P6 stadium led display can be used for advertising, it can also be used as scoreboard in stadium.
2, P6 display brightness is 6500cd/sqm, can be use in indoor and outdoor.
3, Short best view distance for P6 stadium LED displays, audiences can see clearly the led display in near and far place.
4, Big viewing angle, audiences can see led display at every set.
Specification:
Pixel Pitch | 6mm |
Pixel Density | 27777dots/sqm |
Color Configuration | 1R1G1B |
LED Package | SMD3535 |
Module Size | 192mm x 192mm |
Module Resolution | 32dots x 32dots |
Drive Mode | 1/8 Scan, Constant Current |
Brightness | >6500cd/sqm |
Viewing Angle | H: 140°; V:140° |
Refresh Rate | 1000HZ |
Frame Rate | 120frame/sec |
Grey Scale | 16.7M colors(Synchronized) |
Color Temperature | R.G.B brightness 256 level adjustable |
Power Input | AC110V/ 220V ±10％, 50HZ |
Max Power Consumption | 1200W/sqm |
Ave. Power Consumption | 500W/sqm |
Working Temperature | -20℃~+65℃ |
Blind Spot Rate | <1/10000 |
MTBF | >10,000 Hours |
Life Span | >100,000 Hours |
Waterproof | IP65 |
Operating Humidity | 10%~95% |
Control System | Synchronous, 3G, WIFI, USB |
Control PC | With DVI Graphic card |
PC Display Resolution | 1280x1024 |
Operating System | Win 98, Win2000, XP, Win7 ,Win8.etc |
Video Signal Mode | RF,S-Video, RGB, RGBHV, YUV, YC etc |
Certificate | CE, RoHS |
Applications:
Stadium LED Display ,Perimeter LED Screen, Football Stadium LED Screen, Football Perimeter LED Display, Basketball Stadium LED Displays, Soccer LED Display
Baseball Stadium LED Display Screens, Sporting Stadium LED Video Display,Sports Perimeter LED Screen, Sports Club LED Display, LED Score Boards, LED Score Display,LED Digital Scoreboard
Competitive Advantage:
1) we have our own developing and designing team, which ensure our own technological and innovative product for customers.
2) For any customers who have new idea about some products ,just let us know,we can according to your idea provide a unique design of the products.
3) 2 years warranty, more than 10 years life.
4) our working team and sales teams can guarantee a fast and high efficiency after-sales service of our product sold to everywhere of the global.
5) Within 7-15 days, the led display can be sent to you after your payment. Fast delivery time
6) If necessary, our engineers can be sent to your country to assist you to solve all problem.
7) 1% spare parts.( such as led display module, power supply, data cable, power cable)
Product Images:
