Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 6mm | Resolution: | 27777dots/sqm |
|---|---|---|---|
| Cabinet Size: | 576mm X 576mm | Cabinet Material: | Die Casting Aluminum |
| Cabinet Weight: | 9KG | Brightness: | 6500cd/sqm |
| Module Size: | 192mm X 192mm | Led Chip: | Nationstar |
| High Light: | rental LED screen,hire LED screen |
||
Waterproof Concert Rental LED Display Die Casting Aluminum , Slim LED Screen
Feature
1. Ultra thin and light, powerful lock, and hanging design make it easy to assemble and disassemble.
2. High refresh rate, seamless splice, HD video with vivid picture.
3. Module design, tidy and beautiful cabinet, easy for maintenance.
4. Good heat dissipation, no fan and no noise design.
5. At least 48hours aging test before delivery.
Description
1. Wide application: it can be used for any rental application of stage show.
2. Easy and Fast, for both installation and dismantling, without any tools, it takes only 10 seconds to assembly, hanging, pile up and fix installation available.
3. High structure performance, easy connection of each components.
4. Both indoor and outdoor series are compatible, outdoor SMD and DIP screen with IP65 weatherproof level, so it can be used normally in rainy days.
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine, Automatic Glue- pouring Machine,
Solder Paste Printing Machine,Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester, Medium speed Automatic SMT Machine,
Super Mute Terminal Machine, Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI)
Equipement.
Applications
Business Organizations | super market, shopping mall, office building, industrial park, hotel, restaurant, travel agency, pharmacy |
Financial Organizations | banks, insurance company, post office, hospital, school |
Public Places | airport, train/bus station, toll station, bookstore, exhibition hall, stadium, museum, convention center, ticket center, plaza, commercial building |
Entertainments | movie theater, night club, massage room, bar |
Specification
Pixel Pitch | 6mm |
Pixel Density | 27777dots/sqm |
Color Configuration | 1R1G1B |
LED Package | SMD3535 |
Module Size | 192mm x 192mm |
Module Resolution | 32dots x 32dots |
Drive Mode | 1/8 Scan, Constant Current |
Brightness | >6500cd/sqm |
| Cabinet Size | 576mm x 576mm |
| Cabinet Weight | 9KG/pcs |
Viewing Distance | 6m-60m |
Viewing Angle | H: 140°; V:140° |
Refresh Rate | 2000HZ |
Frame Rate | 120frame/sec |
Grey Scale | 16.7M colors(Synchronized) |
Color Temperature | R.G.B brightness 256 level adjustable |
Power Input | AC110V/ 220V ±10％, 50HZ |
Max Power Consumption | 1200W/sqm |
Ave. Power Consumption | 500W/sqm |
Storage Temperature | -40℃~+85℃ |
Working Temperature | -20℃~+65℃ |
Blind Spot Rate | <1/10000 |
MTBF | >10,000 Hours |
Life Span | >100,000 Hours |
Waterproof | IP65 |
Operating Humidity | 10%~95% |
Control System | Synchronous, 3G, WIFI, USB |
Control PC | With DVI Graphic card |
PC Display Resolution | 1280x1024 |
Operating System | Win 98, Win2000, XP, Win7 ,Win8.etc |
Video Signal Mode | RF,S-Video, RGB, RGBHV, YUV, YC etc |
Certificate | CE, RoHS |
Product Images
