8000nits Outdoor Digital Billboard 192mm x 192mm DIP246 Full Color LED Screen

Large Image : 8000nits Outdoor Digital Billboard 192mm x 192mm DIP246 Full Color LED Screen

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	SRYLED
Certification:	CE, LVD, RoHS
Model Number:	SRY - OF - P6

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm
Price:	US$ 1,450 ~ 1,550 / Square Meter
Packaging Details:	Wooden Case (1.06 x 0.50 x 1.16m，case size based on cabinet size. 2 cabinets in 1 wooden case)
Delivery Time:	10-12 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram, PayPal
Supply Ability:	1,000 Square Meter per Month

Contact Now

Detailed Product Description

Pixel Pitch:	6mm	LED Encapsulation:	DIP246
Module Size:	192mm X 192mm	Brightness:	8,000nits
Waterproof:	IP65	MTBF:	10,000hrs
Lifespan:	100,000hrs	Warranty:	2 Full Years
High Light:	LED video billboards , LED digital billboards

8000nits Outdoor Digital Billboard 192mm x 192mm DIP246 Full Color LED Screen

Decription:

Outdoor P6 LED billboard. It has the smaller LED encapsulation. With DIP246 192mm x 192mm LED module, brightness is higher than 8,000nits. For small size billboard, it is a good choice for its high definition.

Features:

1. High brightness

2. Easy to maintain

3. Good color uniformity

4. Energy saving design

5. Low power consumption

6. Light cabinet design

7. 2 full years warranty

Specificition:

Pixel Pitch	6mm
Pixel Density	27,777dots/sqm
Color Configuration	1R1G1B
LED Encapsulation	DIP346
Module Size	192mm x 192mm
Module Resolution	32dots x 32dots
Drive Duty	1/8scan Constant Current
Brightness	>8,000nits
Viewing Distance	6m - 60m
Viewing Angle	H: 120°; V: 70°
Refresh Rate	2,000HZ
Frame Rate	120frame/sec
Grey Grade	256levels of Each Color
Color Grade	16.7M
Power Input	5V-20A, AC110V/ 220V/ 50HZ
Max Power Consumption	1040W/sqm
Ave. Power Consumption	340W/sqm
Storage Temperature	-40℃ ~ +80℃
Working Temperature	-20℃ ~ +60℃
Blind Spot Rate	<1/10000
MTBF	>10,000 Hours
Life Span	>100,000 Hours
Waterproof	IP65
Operating Humidity	10%~95%
Control System	Synchronous, Asynchronous
Operating System	Win 98, Win2000, XP, 07.etc
Input Source	All Format (AVI, MPEG,VOB, RM, etc)
Certificate	CE, LVD, RoHS
