| Pixel Pitch: | 10mm | Module Size: | 320mm X 160mm |
|---|---|---|---|
| Led Chip: | DIP546 | Color: | Red / Yellow / Green / Blue / White |
| Brightness: | Over 2000nit | Waterproof: | IP65 |
| Show Content: | Message, Animation | Display Size: | Customized |
| High Light: | LED information display,programmable led display |
||
1/4 Scan Constant Current Programmable LED Electronic Displays With Remote Control
Description
1. Multi language: English/Spanish/Russia etc.
2. Display one line/two lines/three lines/four lines English characters.
3. Able to show text, graphics and animation.
4. Programmable via either remoter or PC.
5. 25 actions (Snow, Spray, Twinkle, Rotate, Scroll, Star Burst, Wipe, Interlock)
Features
1, 128*32 pixel dots resolution or other size by customized
2, Low power consumption
3, 75mm thickness
4, Adopt front service modules, easier for maintenance
5, IP65 protection level, outdoor solution
6, PC asynchronous control, RF, WIFI, U disk, 3G, GPRS, network, serial port etc
7, Beside red, yellow, green, blue and white, purple can be customized, RGB and RG are also available.
Application
Air station, bus station, railway station, subway station, school, hospital, park, shopping mall, market, bank, bus, taxi roof etc
Specification
| Model No. | 10mm |
| Module Size | 320mm x 160mm |
| Display Size | 1280mm x 320mm or customized |
| Max. Line | 2 lines, 16 English letters per line |
| Pixel configuration | 1R/1Y/1G/1B/1W |
| Density of pixel | 10000dots/sqm |
| Best viewing angle | H: 120°V: 50° |
| Max. power consumption | 100W/sqm |
| Luminance of white balance | ≥2000 nits |
| Driving mode | 1/4 Scan Constant current |
| Working voltage | AC 220V/50HZ |
| Working environment Temperature | -40~ +60°C |
| Related humidity | 10-90RH |
| Control Method | Remote and PC control |
| Specifications | 1.Message is programmable |
| 2.Can display all the languages | |
| 3.Can display 1-2 lines of message | |
| Usage | Service propaganda in finances, post offices, telecom, commerce, hospitals, sports stadiums |
| Policies and decrees issued from government organizations | |
| Instructions, guidance and information issuance in airports and railways |
