| Input Voltage: | 110V - 220V ± 5%, 50HZ | Warranty: | 2 Full Years |
|---|---|---|---|
| Cabinet Material: | Stainless Stell | Lifespan: | 100,000hours |
| High Light: | LED information display,programmable led display |
||
Indoor Single Red Colour P10 Moving Sign Display Area 261cm (width) x 117cm (height)
Quick Information
Indoor Single Red Colour P10 Moving Sign
Display Area : 261cm (width) x 117cm (height)
Panels Size : 32cm (width) x 16cm (height)
Total Panels : 56 Panels (7 row x 8 column)
Transmitter : WIFI Connected Transmission
Colour : 1R (Red Single Colour)
Features
1. High brightness meet the needs of various application environments.
2. Energy saveing design and good performance in color uniformity.
3. Superb workmanship to ensure every processing details.
4. Environmental raw material (LED chips, mask, glue, and steel cabinets).
5. Large viewing angle. Horizontal:120 ° , Vertical: 70°.
Specifications
| Item | Unit | Parameter |
| Pixels(Pixel Pitch) | mm | 10mm |
| Pixel Density | dots/sqm | 10,000dots/sqm |
| Color Configuration | 1R | |
| LED Encapsulation | DIP546 | |
| Drive Duty | scan | 1/4scan |
| Cabinet Resolution | dots | 96dots x 32dots |
| Cabinet Size | mm | 960mm x 320mm |
| Cabinet Weight | kg | ≈15kg |
| Brightness | nits | >2,500nits |
| Best Viewing Distance | m | 10m - 100m |
| Best Viewing Angle | ° | H:120 °, V: 70° |
| Lifespan | hours | >100,000hours |
| MTBF | hours | >10,000hours |
| Working Temperature | Celsius | -20Celsius - +60Celsius |
| Working Humidity | 10% - 95%RH | |
| Warranty | 2 Full Years | |
| Certificate | CE, LVD, RoHS |
1. the red,green,blue, white and yellow color can be choose.
2. outdoor water-proof and semi-outdoor led display design.
3. The size can be design by customer.
4. The simple frame and water-proof cabinet.
5. 2 years warranty and more than 10 years life use.
