Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 10mm | Module Size: | 320mm X 160mm |
|---|---|---|---|
| Led Chip: | DIP546 | Color: | Green/Blue |
| Waterproof: | IP65 | Application: | High Way, Roadside |
| Show Content: | Message, Animation | ||
| High Light: | LED information display,led scrolling message display |
||
Traffic High Way LED Moving Message Display , Green / Blue Single Color LED Display
Description
1, It displays 16 Western characters or 8 Asian Characters.
2, 11 twinkled animation embedded and a brightness font.
3, Brightness and temperature can be automatically adjust by install a sensor.
4, With hierarchical management of programs in menu type so as to keep clear structure and convenient maintenance.
5, Multiple languages and each language can be switched freely.
Features
1. Supports text, number, picture, clock etc.
2. Available color, white, red, green, blue, yellow and RGB.
3. All programs are transmitted by USB flash disk/3G/WIFI/RS232.
4. Used for outdoor or semi-outdoor.
5. More than 40 effects, such as: move to right, move to left, snow fall, mosaic,fan open and etc
6. Show content: Animation, graphic and message.
Application
Entertainment Complexes, Churches, Restaurants, Showrooms, Casinos, Convenience Stores, Banks, Government Facilities, Theatres , Stations, Bus, Taxi Roof, High Way, Shop, Post Office etc
Specification
|
Module details |
Usage: |
Outdoor |
|
Display function: |
Text, graphic, animation |
|
|
Pixel pitch: |
10mm |
|
|
Pixel density: |
10,000dots/sqm |
|
|
Module size: |
320mmx160mm |
|
|
Tube chip color: |
Single color |
|
| Interface | HUB12 | |
| Weight | 0.5KG | |
|
Whole display |
≤0.5mm |
|
|
Constitution: |
1G/1B |
|
|
Resolution: |
16*32 |
|
|
Gray Scale |
256 grades |
|
|
Power supply |
Working voltage: |
AC 110-240V,DC 5V40A |
|
Average power |
100w/sqm |
|
|
Max power |
300w/sqm |
|
|
Main technical parameters |
Brightness: |
2,500cd/sqm |
|
Brightness adjustment |
100 levels by software |
|
|
Refresh frequency |
≥120 Hz |
|
|
Frame frequency |
≥60 Hz |
|
|
Working temperature |
-20°C~+50°C |
|
|
Storage temperature: |
-35°C~+85°C |
|
|
Humidity: |
≤95% |
|
|
Best view distance: |
15-200m |
|
|
Best view angle: |
H: ≥120°; V≥60° |
|
|
MTBF: |
≥5000 hours |
|
|
Lifetime: |
≥100,000 hours |
|
|
Drive mode |
1/4 scanning,constant current |
|
|
Control system |
Operating system |
WIN 98/WIN2000/ |
|
Control method |
Asynchronous |
Our Service
1. Your inquiry related to our products or price will be replied in 24hrs, Monday to Sunday.
2. Export countries : USA, Mexico, Colombia, Turkey, France, Italy, Japan, Netherlands etc
3. Distributoership are offered for your unique design and some our current models
4. Protection of your sales area,ideas of design and all your private information
5. Free training for software operation and technology
6. 2 years warranty
Trade Terms
1, EXW, FOB, CIF, DDU
2, 30% deposit before production and 70% balance before delivery
Product Images
