HD Nationstar Chip SMD2727 P5 Digital LED Advertising Screens 960 x 960mm Cabinet

Large Image : HD Nationstar Chip SMD2727 P5 Digital LED Advertising Screens 960 x 960mm Cabinet

Product Details:

Place of Origin:	China
Brand Name:	SRYLED
Certification:	CE/RoHS
Model Number:	SRY-OF-P5

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm
Price:	1300-1900USD/sqm
Packaging Details:	Wooden box or flight case
Delivery Time:	7-15 days
Payment Terms:	D/A, D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability:	3000sqm per month

Contact Now

Detailed Product Description

Pixel Pitch:	5mm	Module Size:	160mm X 160mm
Cabinet Size:	960mm X 960mm	Drive IC:	MBI Or JXI
Brightness:	6500cd/sqm	Waterproof:	IP65
Led Type:	SMD2727	Led Chip:	Nationstar
High Light:	LED advertising billboards , led advertisement board

HD Nationstar Chip SMD2727 P5 Digital LED Advertising Screens 960 x 960mm Cabinet

Features

1, Rich colors

2, High brightness

3, Good visual effect

4, Diversified display modes

5, Easy operation

6, Available range

Description

1. Excellent visual effect, better visual effect for text and graphic or video

2. Large viewing angle,both H/V can reach 140 degree, getting vivid effect within any position of the viewing range

3. High contrast ratio and good evenness, high uniformity,without mosaic

4. Resist of the high temperature and antioxidation and anti-statiic

5. Any led in each pixel can be respectively replaced, which reduce the cost of the display maintaince

6. Long using life & MTBF

Competitive Advantage

1. 7 years Led industrial experience

2. 24/7 hours online remote support

3. 2 year warranty years

4. Free factory training or engineer support in the spot

Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine, Automatic Glue- pouring Machine,

Solder Paste Printing Machine,Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester, Medium speed Automatic SMT Machine,

Super Mute Terminal Machine, Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI)

Equipement.

Applications

Commercial advertising, buildings, night club, entertainment events, business establishments, stock exchange centers, bus station, schools, telecommunications, stadiums, shopping malls, railways, airports, high way etc.

Specification

Pixel Pitch	5mm
Pixel Density	40000dots/sqm
Color Configuration	1R1G1B
LED Package	SMD2727
Module Size	160mm x 160mm
Module Resolution	32dots x 32dots
Drive Mode	1/8 Scan, Constant Current
Led Chip	Nationstar
Drive IC	MBI or JXI
Power Supply	G-energy, Chuanglian, Meanwell
Module Weight	0.5KG
Module Thickness	2.8CM
Interface	HUB75
Brightness	Over 6500cd/sqm
Best Viewing Distance	5m-100m
Viewing Angle	H: 160°; V:160°
Refresh Rate	1800HZ
Frame Rate	120frame/sec
Grey Scale	16.7M colors(Synchronized)
Color Temperature	R.G.B brightness 256 level adjustable
Power Input	AC110V/ 220V ±10％, 50HZ
Max Power Consumption	1100W/sqm
Ave. Power Consumption	500W/sqm
Storage Temperature	-35℃~+85℃
Working Temperature	-20℃~+65℃
Blind Spot Rate	<1/10000
MTBF	>10,000 Hours
Life Span	>100,000 Hours
Waterproof	IP65
Operating Humidity	10%~95%
Control System	LINSN, NOVA, XIXUN, HD
Control PC	With DVI Graphic card
Operating System	Win 98, Win2000, XP, Win7 ,Win8.etc
Video Signal Mode	RF,S-Video, RGB, RGBHV, YUV, YC etc
Certificate	CE, RoHS
