Product Details:
Payment & Shipping Terms:
|
| Pixel Pitch: | 5mm | Module Size: | 160mm X 160mm |
|---|---|---|---|
| Led Type: | SMD2727 | Drive Method: | 1/8 Scan |
| Material: | Die Casting Aluminum | Warranty: | 2 Years |
| Refresh Rate: | 2000Hz | Control System: | LINSN |
| Highlight: | rental LED screen,hire LED screen |
||
RGB Tube Chip SMD2727 P5 Super Slim Led Display Screen 2000Hz
Description
1. New design,suitable for outdoor&indoor live show, brightness adjustable facing the sunshine directly, waterproof IP65. neither flick nor color blocks
2. Die casting aluminum cabinet size:640x640mm, Seamless connection,0.1mm gapline between 2 cabinets
3. Fast lock for quick and easy installation, Maximum support 50pcs hanging in a collum
4. Fast locks design, cabinets can be easily assemblied in 10 seconds
5. Dual-maintenance, Fanless, noiseless, low power comsumption
6. Vertical/Horizontal viewing angle 140 degree,Calibration for high quality picture
7. Support all media format, also support DVI/HDMI/3G/HD/SD/SDI display mode,applicable for TV program, VCD/DVD and live show.
8. Smart mode available(optional) to monitor the overall working hours and temperature of each cabinet
9. Cost saving for installation and maintenance, Hotplug in power supply
Advantages
1. Vivid and brilliant color, sharp and smooth images.
2. Plug & Play, No tools, 10 Seconds for one panel installation / dismantle.
3. One set cabinet structure is compatible with various pixel pitches, easily have another new screen by
changing led modules.
4. Support different shapes installation: Flat and curved ,create infinite stage styles.
5. Superb performance/price ratio solution for rental market.
6. 24/7 professional after sales service, and on-site service is available.
Specification
|
Pixel Pitch |
5mm |
|
Pixel Density |
40000dots/sqm |
|
Color Configuration |
1R1G1B |
|
LED Package |
SMD2727 |
|
Module Size |
320mm x 160mm/ 160mm x 160mm |
|
Module Resolution |
64dots x 32dots/ 32dots x 32dots |
|
Drive Mode |
1/8 Scan |
|
Standard Cabinet Size |
640mm x 640mm |
|
Cabinet Weight |
12KG |
|
Brightness |
≥6500 cd/sqm |
|
Viewing Distance |
5m-50m |
|
Viewing Angle |
H: 140°; V:120° |
|
Refresh Rate |
2000HZ, adjustable by software |
|
Frame Rate |
120frame/s |
|
Grey Scale |
16.7M colors(Synchronized) |
|
Color Temperature |
R.G.B brightness 256 level adjustable |
|
Power Input |
AC110V/ 220V ±10％, 50HZ |
|
Max Power Consumption |
800W/sqm |
|
Ave. Power Consumption |
300W/sqm |
|
Storage Temperature |
-30℃~+70℃ |
|
Working Temperature |
-20℃~+50℃ |
|
Blind Spot Rate |
<1/10000 |
|
MTBF |
>10,000 Hours |
|
Life Span |
>100,000 Hours |
|
Waterproof Level |
IP43 |
|
Operating Humidity |
10%~90% RH |
|
Control Method |
Synchronous, Asynchronous, 3G,WIFI,USB |
|
Control PC |
With DVI Graphic card |
|
Operating System |
Win 98, Win2000, XP, Win7, Win8 |
|
Video Signal Mode |
RF, S-Video, RGB, RGBHV, YUV, YC etc |
|
Certificate |
CE, RoHS |
Applications
Ideal for super market, Shopping mall, hospital, bank, enterprises, government offices, exhibition hall, hotel, sports stadium center, customs, staging area,car exhibition, airport, transportation, parks, TV
