| Pixel Pitch: | 3mm | Size: | 192mm X 192mm |
|---|---|---|---|
| Refresh: | 3000HZ | Interface: | HUB75 |
| Control Way: | Synchronous, USB, 3G, WIFI | Module Weight: | 0.2KG/pcs |
| High Light: | Indoor LED Display Module,LED screen Module |
||
192mm x 192mm industrial P3 LED video display Small Pitch Module
Description
1. Wide view angle
With 120/120degree view angle ,bring a wonderful image
2. Light, thin and intensive design offers more space to be creative
3. Information source can be camera, video, VCD, DVD, LD, TV and so on; Clear picture without flicker and distortion
4. Black LED and light absorbing mask patent increase the display effect
5. High definition guarantee excellent performance
Vivid and exact picture, minimum noise, advanced test equipment, support any PC operation system
and play a variety of information like video, word, flash, music, clock, graph etc. LED billboard Cabinet design for easy install and dismantle
Features
1, High refresh, 3000HZ .
2, High contrast, 4000:1.
3, High resolution, 111111dots/sqm.
4, Best viewing distance, 3 - 30m.
5, Viewing angle, H: 140°; V:140°.
Specification
|
Pixel Pitch |
3mm |
|
Pixel Density |
111111dots/sqm |
|
Color Configuration |
1R1G1B |
|
LED Package |
SMD2121 |
| Module Thickness | 18cm |
|
Module Resolution |
64dots x 64dots/64dots x 32dots |
|
Standard Cabinet Size |
576mm x 576mm |
| Drive IC | JXI 5020 |
|
Brightness |
≥2000 cd/sqm |
|
Viewing Angle |
H: 140°; V:140° |
|
Grey Scale |
16.7M colors(Synchronized) |
|
Color Temperature |
R.G.B brightness 256 level adjustable |
|
Power Input |
AC110V/ 220V ±10％, 50HZ |
|
Ave. Power Consumption |
300W/sqm |
|
Working Temperature |
-20℃~+50℃ |
|
Blind Spot Rate |
<1/10000 |
|
Life Span |
>100,000 Hours |
|
Operating Humidity |
10%~90% RH |
|
Control Method |
Synchronous, Asynchronous, 3G,WIFI,USB |
|
Operating System |
Win 98, Win2000, XP, Win7, Win8, Win10 |
FAQ
1.What is the payment method?
We support a variety of payment methods, the most common is the TT.
2.Can it play HD video?
Yes, it can realize HD video function with video processor.
3.What's the controlling system?
Our standard controlling system for this model is Linsn, Novastar. Also support other controlling system, like Xixun,TF, Colorlight, etc.
4.What's the difference between DIP(1R1G1B) and sSMD(One LED, 3 in 1) ?
SMD(One LED, 3 in 1) LED Display, one pixel has one LED lamp, 3 led chips in one LED Lamp;
Traditional DIP( 1R1G1B) use 3 LED Lamp in one pixel.
SMD(One LED), reduced the LED on the screens,it reduced grainy of the screen, and improve the uniform of the screen, this will make the screen have a more wide viewing angle and smooth image. With the technology advanced and SMD brightness improved, SMD is more and more used outdoor.
5. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF etc. You can choose the one which is the most convenient or cost effective for you.
