Double Sides Ultra Bright digital outdoor led screen Sign 160mm x 160mm

Large Image : Double Sides Ultra Bright digital outdoor led screen Sign 160mm x 160mm

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	SRYLED
Certification:	CE, LVD, RoHS
Model Number:	SRY - OFS - P10

Payment & Shipping Terms:

Minimum Order Quantity:	1sqm
Price:	US$ 720 ~ 750 / Square Meter
Packaging Details:	Wooden Case (1.05x0.50x1.15m，case size based on cabinet size. 2 cabinets in 1 wooden case)
Delivery Time:	10-12 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram, PayPal
Supply Ability:	1,000 Square Meter per Month

Contact Now

Detailed Product Description

Pixel Pitch:	10mm	LED Encapsulation:	DIP346
Module Size:	160mm X 160mm	Brightness:	7,500nits
Waterproof:	IP65	MTBF:	10,000hrs
Lifespan:	100,000hrs	Warranty:	2 Full Years
High Light:	LED advertising billboards , LED digital billboards

Double Sides Ultra Bright digital outdoor led screen Sign 160mm x 160mm

Decription:

Outdoor Double Sides LED Billboard, 10mm Ultra Bright Waterproof LED Billboard Sign, brightness is higher than 7,500nits. Best viewing distance is 10m ~ 100m. Max power consumption is 750W/sqm. To sum up this kind P10 sells very well in LED displays area. It is the best seller among all LED displays.

Features:

1. High brightness

2. Easy to maintain

3. Good color uniformity

4. Low power consumption

5. Slim screen thickness

6. Light cabinet design

7. 100,000hrs lifespan

Specificition:

Pixel Pitch	10mm
Pixel Density	10,000dots/sqm
Color Configuration	1R1G1B
LED Encapsulation	DIP346
Module Size	160mm x 160mm
Module Resolution	16dots x 16dots
Drive Duty	1/4scan Constant Current
Brightness	>7,500nits
Viewing Distance	10m - 100m
Viewing Angle	H: 120°; V: 70°
Refresh Rate	2,000HZ
Frame Rate	120frame/sec
Grey Grade	256levels of Each Color
Color Grade	16.7M
Power Input	AC110V/ 220V/ 50HZ
Max Power Consumption	750W/sqm
Ave. Power Consumption	250W/sqm
Storage Temperature	-40℃~+80℃
Working Temperature	-20℃~+60℃
Blind Spot Rate	<1/10000
MTBF	>10,000 Hours
Life Span	>100,000 Hours
Waterproof	IP65
Operating Humidity	10%~95%
Control System	Synchronous, Asynchronous
Operating System	Win 98, Win2000, XP, 07.etc
Input Source	All Format (AVI, MPEG,VOB, RM, etc)
Certificate	CE, LVD, RoHS
