P4mm Outdoor Full Color LED Display / LED Video Wall Advertising Ultra Bright
Quick Information
1. Pixel Pitch: 4mm
2. Color Configuration: 1R1G1B 3in1
3. LED Encapsulation: SMD1921
4. Module Size: 256mm x 128mm
5. Cabinet Size: 768mm x 768mm
6. Cabinet Material: Stainless Steel
Features
1. Large viewing angle. Horizontal:120 ° , Vertical: 120°.
2. Superb workmanship to ensure every processing details.
3. Energy saveing design and good performance in color uniformity.
4. High brightness meet the needs of various application environments.
5. Environmental raw material (LED chips, mask, glue, and steel cabinets).
Specifications
| Item | Unit | Parameter |
| Pixels(Pixel Pitch) | mm | 4mm |
| Pixel Density | dots/sqm | 62,500dots/sqm |
| Color Configuration | 1R1G1B 3in1 | |
| LED Encapsulation | SMD1921 | |
| Drive Duty | scan | 1/8scan |
| Cabinet Resolution | dots | 192dots x 192dots |
| Cabinet Size | mm | 768mm x 768mm |
| Cabinet Weight | kg | ≈25kg |
| Brightness | nits | >6,500nits |
| Best Viewing Distance | m | 4m - 4m |
| Best Viewing Angle | ° | H:120 °, V: 120° |
| Lifespan | hours | >100,000hours |
| MTBF | hours | >10,000hours |
| Working Temperature | Celsius | -20Celsius - +60Celsius |
| Working Humidity | 10% - 95%RH | |
| Warranty | 2 Full Years | |
| Certificate | CE, LVD, RoHS |
Light: Cabinet size 768mm*768mm, only25kg comparing to more than 25 kg of common cabinet. Saving time and labor cost.
Thin: It is die-casting aluminum cabinet, thus it is featured by high strength, toughness, precision and it is hard to be deformed. The edge is just 33mm comparing to the 160mm of common cabinet.
Fast: There is fast locking device in four corners. It takes only 10 seconds to assemble one cabinet by pushing the handle 90 degree. It is fast and precise assembling.
Easy: The cabinet is modular designed, each cabinet of the screen can be easily dismantled and assembled(replaced).
Compatible: New structure design satisfies hoisting and ground-support assembling. P4, P5.33, P6.4, P10.66, P12.8 and P16 are compatible.
Low: Excellent heat dissipation design, no fans and air conditioning are required. Low noise, light weight, low cost for transportation and assembling without tools with low cost for assembling.
