| Input Voltage: | AC 110V - 220V ± 5%, 50HZ | Warranty: | 2 Full Years |
|---|---|---|---|
| Cabinet Material: | Stainless Steel | Lifespan: | 100,000hours |
| High Light: | outdoor advertising LED display,outside advertising boards |
||
5.76m x 3.072m P12mm Outdoor Full Color LED Display Screen High Brightness
Quick Information
1. Pixel Pitch: 12mm
2. Color Configuration: 1R1G1B
3. LED Encapsulation: DIP346
4. Module Size: 192mm x 192mm
5. Cabinet Size: 768mm x 768mm
6. Cabinet Material: Stainless Steel
Features
1. Large viewing angle. Horizontal:120 ° , Vertical: 70°.
2. Superb workmanship to ensure every processing details.
3. Energy saveing design and good performance in color uniformity.
4. High brightness meet the needs of various application environments.
5. Environmental raw material (LED chips, mask, glue, and steel cabinets).
Specifications
| Item | Unit | Parameter |
| Pixels(Pixel Pitch) | mm | 12mm |
| Pixel Density | dots/sqm | 6,944dots/sqm |
| Color Configuration | 1R1G1B | |
| LED Encapsulation | DIP346 | |
| Drive Duty | scan | 1/4scan |
| Cabinet Resolution | dots | 64dots x 64dots |
| Cabinet Size | mm | 768mm x 768mm |
| Cabinet Weight | kg | ≈25kg |
| Brightness | nits | >7,500nits |
| Best Viewing Distance | m | 12m - 120m |
| Best Viewing Angle | ° | H:120 °, V: 120° |
| Lifespan | hours | >100,000hours |
| MTBF | hours | >10,000hours |
| Working Temperature | Celsius | -20Celsius - +60Celsius |
| Working Humidity | 10% - 95%RH | |
| Warranty | 2 Full Years | |
| Certificate | CE, LVD, RoHS |
1. Multivariate Structural Design:
The cabinets can be installed by ground stacking insallation,column installation,hanging insallation and other insallation,and can also be curved switching to meet the various needs of clients effect.
2. Convenient Maintenance Operations:
Disassembling modules without opening back cover.
3. Reliable Protection Class:
Cabinet's protection grade in front sides and real sides all reach IP65,certified through SGS third party.Screen can be used in wind,rain and snow weather.
4. Stable Performance:
Internal connection within cabinet is simple,HUB card and modules use copper-plated pin directly connected.As we all know,the fewer components used in electronic products,the lower failure rate.Compared to traditional cable connection,I-Magic work more stable and reliable.
5. Extremely High Accuracy
Use of aluminum structure for the cabinets,one-time die-casting,creating exquisite work,the flatness of the entire screen when assembing is very high,and the gap between cabinets is less than 0.3mm,can't be detected by naked eyes,outstanding display effect.
